CMS-153MV

CMS-153MV

A Legacy of Trust, Innovation, and Excellence


  • FEATURES
  1. Optimized 2-way speaker system for smaller cinemas—up to 11 m in length
  2. Passive crossover requires only one amplifier channel
  3. CMS-153MV 2x15-inch (380mm) woofer with 2.5-inch (64 mm) voice coil
  4. 1.75-inch (44 mm) voice coil HF compression driver
  5. Shallow profile with depth 238mm for minimum behind-screen
  • space  requirements
  1. Bonding post connectors

  • SPECIFICATION

     Model     CMS-153MV
     Speaker Unit     15"x2 + 1.75"x1
     Frequency Response       40Hz ~ 20kHz
     Impedance     4Ω
     Rated Output Power     600W
     Sensitivity     101dB
     HxV Angle     90° x 40°
     Crossover     1.5kHz
     Distortion     ≤1%
     Dimensions (WxDxH)      881 x 260 x 1415 mm
     Net Weights     60kg
